8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail

1 پی سی
MOQ
قابل مذاکره
قیمت
8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail
امکانات گالری توضیحات محصول درخواست نقل قول
امکانات
مشخصات
نام محصول: سوئیچ DIN PoE 8 پورت گیگابیتی
فیبر: اسلات های 2*1G SFP
مس: 8*10/100/1000Mbps RJ45/PoE
خروجی پو: DC48V، فعال PoE
بودجه PoE: 240W
چیپست: REALTEK
اطلاعات اولیه
محل منبع: شنژن ، چین
نام تجاری: Olycom
گواهی: CE RoHS FCC ISO9001
شماره مدل: IM-FP288GM
پرداخت
جزئیات بسته بندی: 1 عدد در جعبه، 0.9 کیلوگرم وزن ناخالص
زمان تحویل: 4 تا 7 روز کاری
شرایط پرداخت: T/T ، PayPal
قابلیت ارائه: 2000pcs در ماه
توضیحات محصول

Olycom Gigabit managed PoE fiber switch 8 Port



Key Features of Industrial network switch



  • Support power on POE IP cameras through the wireless access point (AP) of 5 categories of Ethernet cable.
  • IEEE 802.3af/at/bt power on to 1 ~ 8 RJ45 ports
  • 8 x 10/100/1000Mbps Auto-sensing RJ45 ports
  • 2 x 1000Mbps SFP fiber port
  • 1 x console port
  • 4 KV Ethernet surge protection, adapt to a harsh outdoor environment
  • Support Auto MDI/MDIX
  • Flow control mode: full duplex with IEEE 802.3x standard,
  • half-duplex with Back pressure standard
  • IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
  • A store-and-forward switching mechanism
  • Operating environment temperature: -40 ° ~75 ° c
  • Support bus/star topology, ring structure, support ITU-T G.8032/Y.1344 ERPS
  • Support SNMPv1, v2, v3, Web management, support user login password protection and other device configuration methods
  • Support ACL, port-based MAC filtering, MAC address binding, port-based 802.1x authentication, system automatic defense, prevent DDOS and other attacks;
  • Support VLAN: support port VLAN and 802.1Q Tag
  • Support QoS 4-level priority, static LACP, support port-based one-way and two-way traffic mirroring
  • Support IGMP Snooping v1/v2, port bandwidth control, broadcast storm suppression
  • Support SNTP protocol
  • Support MIB library opening to meet the requirements of operation and maintenance
  • Support SNMPv3, IEEE 802.1X, HTTPS and SSH, enhancing network security
  • Support WEB, CLI, Telnet, Windows utility and SNMP management methods
  • Reset: Support restart and restore default configuration

Specification of 8 Port Ethernet Switch

Product Name 10/100/1000Mbps Managed Industrial POE Fiber Switch (2F+8TP)
Model No. IM-FP288GM
Port

2 x 1000Mpbs SFP port

SM:1310nm/1550nm,20Km ;1490nm/1550nm, 40~120Km; MM:1310nm, 2Km; 8x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)
Standard IEEE 802.3, IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.1Q VLAN Tagging, IEEE 802.1p CoS, IEEE 802.1X Authentication, IEEE 802.3ad Link Aggregation Protocol: IGMPv1/v2, SNMPv1/v2c/v3, DHCP ClientTFTP, HTTP, HTTPS, Telnet, Syslog SSH, SNMP Inform, DDM, Ping/tracert detection, MIB library: MIB-II, Ethernet-Like MIB
Managed

☆Support VLAN: 802.1Q VLAN (4K), Port-based VLAN

☆ Jumbo frame processing: 9k

☆ Report buffer: 64K

☆ Broadcast storm suppression: support broadcast, multicast, unknown unicast suppression

☆ Flow control: Adopt IEEE802.3x negotiation flow control, CAR function, speed limit step size is 1Kb

☆ Ring network function: support ITU-T G.8032 /Y.1344 ERPS

☆ Multicast protocol: IGMPv1/2/3 Snooping

☆ Port management: support port isolation and port aggregation

☆ DHCP management: support DHCP Snooping, option 82

☆ QoS mechanism: 802.1p; support port default priority marking, each port has at least 4 queues with different priorities

☆ Security: login access authentication, login password modification, MAC address filtering, support dynamic or static MAC address learning / support ARP learning function off and on, ARP message speed limit / support IP+MAC+ port manual and automatic scanning binding Set IEEE 802.1x (Port based, MAC based), can transparently transmit 802.1x data packets/port loop detection
Switching Features

Exchange capacity: 20Gbps Packet forwarding rate: 14.8Mpps

MAC address table: 4K Swap delay: <5μs

Transmission method: store and forward
Power supply

Input voltage:DC 48-52V; No-load power<5W

Reverse connection: support

Overload protection: support

Redundant protection: support
Environment

Working Temp:-40°～ 85°C ; Storage Temp:-40°～ 85°C;

Working humidity:5%～95%, non-condensing
Industry Standards

EMI:FCC Part 15 Subpart B Class A,EN 55022 Class A

EMS:EN 61000-4-2 (ESD) Level 3,EN 61000-4-3 (RS) Level 3, EN 61000-4-4 (EFT) Level 3,EN 61000-4-5 (Surge) Level 3, EN 61000-4-6 (CS) Level 3,EN 61000-4-8

Traffic Control:NEMA-TS2 Vibration:IEC 60068-2-6

Freefall:IEC 60068-2-32 Shock:IEC 60068-2-27 Rail Traffic:EN 50121-4
Mechanical information

Shell:Corrugated metal shell; Safety class:IP40

Dimension:158*115*60mm

Mounting method:Din-rail mounting
Warranty Replacement within 1 year; 5 years repairing

Application of Managed PoE Switch

8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail 0


The IM-FP288GM is ideal for industrial Ethernet, transportation, and surveillance networks requiring robust connectivity and intelligent PoE power management.
It ensures stable communication for IP cameras, access points, PLCs, and sensors across factory automation systems, traffic monitoring, power substations, and smart city infrastructure.

With its rugged design, intelligent management, and reliable performance, the IM-FP288GM delivers secure, real-time network connectivity for industrial and outdoor applications.



WEB GUI



8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail 1



8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail 2



Accessory



Industrial Optical Module
OSPL1G05D 1000BASE-SX
OSPL1G06D 1000BASE-SX(1310nm)
OSPL1G20D 1000BASE-LX
OSPL1G40D 1000BASE-EX
OSBL1G20D-35 1000BASE-BX-U(TX 1310 RX1550)
OSBL1G20D-53 1000BASE-BX-D(TX 1550 RX1310)
Industrial DIN Power Supply
IM-DAC220/DC48V2.5A AC220V to DC48V2.5A, -40℃～70℃
IM-DAC220/DC48V5A AC220V to DC48V5A, -40℃～70℃
IM-DAC220/DC48V10A AC220V to DC48V10A, -40℃～70℃

8 Port Managed Industrial PoE Switch Gigabit SFP Fiber 240W Actice PoE DC48V DIN Rail 3
